Details

Tilt is a dynamic, powerful SEE SAW EQ control. This control has a central neutral position. Turning the control clockwise increases the overall mid to high frequencies and decreases the lows thereby giving your sound more presence, which can be useful for cutting through live band situations. Turning the control anti clockwise reduces the overall mid to high frequencies and increases the lows making your overall sound rounder.


Headphones socket


It is important that when you activate an effect there is no switching noise. So, we take great care in designing a switching system that is totally silent in operation. The only thing you should here is a great sounding product.


FX loops are important as they allow you to add effects to the signal path in a specific place between the pre-amp and the output section on an amplifier. This is where FX loops are important as it allows you to put time-based FX after the distorted pre-amp section. For example, delayed distortion sounds different to distorted delay – try it.


Status LED


High quality switching components


Key Features

  • 2 Channels
  • FET and Tube with Blend Switch
  • 3 Band EQ
  • Low Mid with switchable frequencies
  • DI Out with pre/post source select
  • Ground Lift
  • FX Loop
  • AUX in
  • Phones out
  • Passive Input
  • Active input
  • Link out
  • FET Volume
  • TUBE Drive & Volume
  • Regulated 9V DC PSU, centre negative, 2.1x10mm connector type. (Not Included)
  • TILT 'EQ Seesaw' function

Specifications

  • Item dimensions: 60mm x 150mm x 125mm (HWD)
  • Carton dimensions: 93mm x 201mm x 191mm (HWD)
  • Item weight: 0.75kg
